Lufft Ventus UMB Ultrasonic Wind Sensor

This sensor is part of the UMB family of sensors with both digital and analogue outputs. There are no mechanical parts to maintain, and is heated so can be used in harsh, cold conditions. It outputs wind direction, wind speed, virtual temperature (calculated) and air pressure

Wind Direction

• Range: 0-359.9 degrees
• Resolution: 0.1 degree
• Accuracy: <2 degrees
• Startup threshold: 0.1 m/s
• Rate: 15 measurements per second

Wind Speed

• Range: 0-75 m/s
• Resolution: 0.1 m/s
• Accuracy: +/- 0.2 m/s
• Startup threshold: 0.1 m/s
• Rate: 15 measurements per second

Virtual Temperature:

• Range: -50 - +70 deg C
• Resolution: 0.1 deg C
• Accuracy: +/- 2 deg C

Air Pressure:

• Range: 300 - 1200 hPa
• Accuracy: +/- 1.5 hPa

Details:

• Selectable output - NMEA, UMB-ASCII, UMB-Binary, Modbus, SDI-12, 4-20ma, 0-10VDC, 0-20mA, 2-10VDC, 0-2000Hz
• Operating temperature: -40 to +60 C with heating, -20 to +60 without heating
• Input power: 24VDC
• Housing: Aluminium, seawater proof, IP65
